Spinel has been doing business in the soft magnetic ferrite industry for 40 years. Our magnetic materials are characterized by diverse types, stable performance and wide application. Currently, we have more than 10 types of raw materials and over 900 specification choices for Ferrite Core.
The magnetic rods are most often applied in induction coils, automobile ignition coils, ABS coils and power inductors.
Main Advantages
1. The ferromagnetic core is made from high-temperature low-consumption material and high magnetic permeability material, showing a relatively low power loss at high temperature.
2. If the exiting types fail to reach your requirements, we also provide outstanding custom service according to your actual demands.
Packaging
Before leaving the factory, all magnetic products must be well packed to avoid any possible breakage or damage. Additionally, the packaging manner can also be decided by customers.
Name | FIG | Drawing No. | Dimensions(mm) | Weight | ||
A | B | C | (g) | |||
R3*8 | 1 | 600 | 3.0±0.15 | 18.0±0.3 | 0.6 | |
R5*15 | 1 | 574 | 5.0-0.2 | 15.0-0.2 | 1.4 | |
R6*16 | 1 | 510 | 6.0±0.1 | 16.0±0.15 | 2.2 | |
R6*18 | 1 | 528 | 6.0-0.2 | 18.0-0.2 | 2.4 | |
R6*30 | 1 | 575 | 6.0±0.25 | 30.0±0.3 | 4.05 | |
R6*40 | 1 | 529 | 6.0-0.2 | 40.0-0.2 | 5.4 | |
R6*41 | 2 | 1170 | 6.0±0.3 | 41.0±0.7 | 5.0±0.2 | |
R6*5 | 1 | 570 | 6.0±0.1 | 15.0±0.15 | 2.05 | |
R6*50 | 1 | 581 | 6.0±0.3 | 50±0.6 | 6.8 | |
R6*63 | 2 | 1710 | 63.0±0.7 | 6.0±0.2 | ||
R6*85 | 2 | 1711 | 85.0±0.7 | 6.0±0.2 | ||
R6.35*30 | 1 | 548 | 6.35±0.35 | 30.0-0.5 | 4.5 | |
R7*25 | 1 | 530 | 7.0-0.2 | 25.0-0.2 | 4.6 | |
R10*25 | 1 | 545 | 10.0-0.4 | 25.0±0.2 | 9.4 | |
R10*50 | 2 | 587 | 10.0-0.5 | 50.0+1.0-0.5 | 9.0+0.2-0.1 | 18 |
R47 | 1 | 1199 | 47.0±0.3 | 0.7±0.07 | 5.35 | |
R48*2 | 1 | 1143 | 48±0.6 | 2.0±0.15 | 6 |
