<start> <p>Spinel has accumulated lots of experience in producing a comprehensive range of high-quality Ferrite Core. The majority of ferrite core are used in drive transformers, high-frequency transformers, power inductors and high-frequency choke coils.</p>
<p><strong>Characteristics</strong><br />
1. We have prepared over 10 types of raw materials to produce magnetic elements of over 900 specifications, with reliable performance and wide application.<br />
2. To ensure great quality and high cost effectiveness, our company imported Toshiba kilns, Tamagawa presses and state-of-the-art CNC grinding machines, as well as brought in advanced sintering techniques and forming techniques. That's why we can achieve an annual production of 12,000 tons.<br />
3. In order for quality assurance, we selected reliable raw material manufacturers. Main ferric oxide suppliers include Japan JFE, Korea RG and China Steel Corporation. Main manganous-manganic oxide manufacturers are Hunan Special Metal Materials Factory and Kingray New Materials Science & Technology Co., Ltd.<br />
4. We pay great attention to the product quality and carry out strict tests from raw material to final products. High-precision testing instruments include Bruker X-ray fluorescence spectrometer, high-frequency power dissipation measuring instrument, S4 PIONEER X-ray fluorescence spectrophotometer, etc.</p>
<p><strong>Packaging</strong><br />
Before leaving the factory, all magnetic products must be well packed to avoid any possible breakage or damage. Additionally, the packaging manner can also be decided by customers.</p>
<div class="img_center"> <img src="/upload/3799/o/1-7-ec-magnetic-material-02.jpg" class="img-responsive" title="EC" /> </div>
<strong>Technical Parameters </strong><br />
<div class="table-responsive">
<table class="table table-hover ke-zeroborder table-striped">
<tbody><tr> <td rowspan="2"> Name </td>
<td rowspan="2"> Drawing No. </td>
<td colspan="7"> Dimensions(mm) </td>
<td> Weight </td>
<td colspan="6"> Parameters (mm) </td>
<td> AL±25% (nN/H2) </td>
</tr>
<tr> <td> A </td>
<td> B </td>
<td> B2 </td>
<td> C </td>
<td> D </td>
<td> E </td>
<td> F </td>
<td> (g) </td>
<td> C1 </td>
<td> Le(mm) </td>
<td> Ae(mm2) </td>
<td> Ve(mm3) </td>
<td> Aw(mm2) </td>
<td> Amin(mm2) </td>
<td> JF40 </td>
</tr>
<tr> <td> EC2520 </td>
<td> 960 </td>
<td> 25.0±0.3 </td>
<td> 19.5±0.3 </td>
<td></td>
<td> 9.5±0.2 </td>
<td> 11.0±0.15 </td>
<td> 5.8±0.15 </td>
<td> 9.05±0.15 </td>
<td> 16.4 </td>
<td> 0.6 </td>
<td> 43 </td>
<td> 71.3 </td>
<td> 3063.6 </td>
<td> 116 </td>
<td> 70.88 </td>
<td> 2500 </td>
</tr>
<tr> <td> EC2536 </td>
<td> 1219 </td>
<td> 24.7±0.6 </td>
<td> 18.8min </td>
<td> 17.8 min </td>
<td> 8.3±0.3 </td>
<td> 8.3±0.3 </td>
<td> 13.65±0.2 </td>
<td> 18.0±0.2 </td>
<td> 21.3 </td>
<td> 1.44 </td>
<td> 78.07 </td>
<td> 54.32 </td>
<td> 4240.9 </td>
<td></td>
<td></td>
<td> 1450 </td>
</tr>
<tr> <td> EC2619 </td>
<td> 809 </td>
<td> 25.5±0.5 </td>
<td> 19.8min </td>
<td></td>
<td> 7.5±0.15 </td>
<td> 7.5±0.2 </td>
<td> 6.4±0.2 </td>
<td> 9.5±0.2 </td>
<td> 11.7 </td>
<td> 1.08 </td>
<td> 48.28 </td>
<td> 44.67 </td>
<td> 2156 </td>
<td> 157.4 </td>
<td> 44.18 </td>
<td> 1800 </td>
</tr>
<tr> <td> EC28 </td>
<td> 737-1 </td>
<td> 28.5±0.5 </td>
<td> 21.5min </td>
<td> 20.0 min </td>
<td> 9.9±0.25 </td>
<td> 11.4±0.25 </td>
<td> 12.5±0.3 </td>
<td> 16.9±0.3 </td>
<td> 33.3 </td>
<td> 0.93 </td>
<td> 75.5 </td>
<td> 81.4 </td>
<td> 6140 </td>
<td></td>
<td></td>
<td> 2300 </td>
</tr>
<tr> <td> EC2820B </td>
<td> 1025 </td>
<td> 28.5±0.5 </td>
<td> 21.5min </td>
<td> 19.5 min </td>
<td> 9.9±0.25 </td>
<td> 11.4±0.25 </td>
<td> 6.5+0.2-0.12 </td>
<td> 10.0±0.2 </td>
<td> 19.6 </td>
<td> 0.6 </td>
<td> 49.8 </td>
<td> 80.5 </td>
<td> 4007.8 </td>
<td> 150.8 </td>
<td> 76.98 </td>
<td> 2500 </td>
</tr>
<tr> <td> EC2828 </td>
<td> 737 </td>
<td> 28.5±0.5 </td>
<td> 21.5min </td>
<td></td>
<td> 9.9±0.25 </td>
<td> 11.4±0.25 </td>
<td> 9.8±0.2 </td>
<td> 14.0±0.3 </td>
<td> 28.5 </td>
<td> 0.74 </td>
<td> 64 </td>
<td> 81.4 </td>
<td> 5260 </td>
<td> 235.2 </td>
<td> 76.98 </td>
<td> 2800 </td>
</tr>
<tr> <td> EC2828A </td>
<td> 805 </td>
<td> 28.5±0.5 </td>
<td> 21.5min </td>
<td></td>
<td> 9.9±0.25 </td>
<td> 11.0±0.25 </td>
<td> 10.0±0.2 </td>
<td> 14.0±0.3 </td>
<td> 28.4 </td>
<td> 0.74 </td>
<td> 65.6 </td>
<td> 79.7 </td>
<td> 5230 </td>
<td> 322 </td>
<td> 76.98 </td>
<td> 2800 </td>
</tr>
<tr> <td> EC2834 </td>
<td> 737 </td>
<td> 28.5±0.5 </td>
<td> 21.5min </td>
<td></td>
<td> 9.9±0.25 </td>
<td> 11.4±0.25 </td>
<td> 12.5±0.2 </td>
<td> 16.9±0.3 </td>
<td> 33.3 </td>
<td> 0.93 </td>
<td> 75.5 </td>
<td> 81.4 </td>
<td> 6140 </td>
<td> 300 </td>
<td> 76.98 </td>
<td> 2500 </td>
</tr>
<tr> <td> EC29.4 </td>
<td> 466 </td>
<td> 29.4+0.8-0.6 </td>
<td> 22.6min </td>
<td></td>
<td> 9.9±0.25 </td>
<td> 11.4±0.25 </td>
<td> 10.0±0.3 </td>
<td> 14.2±0.3 </td>
<td> 30 </td>
<td> 0.78 </td>
<td> 65.58 </td>
<td> 84.25 </td>
<td> 5525 </td>
<td> 254 </td>
<td> 76.98 </td>
<td> 2500 </td>
</tr>
<tr> <td> EC29.4C </td>
<td> 1019 </td>
<td> 29.5±0.5 </td>
<td> 22.9min </td>
<td> 21.1 min </td>
<td> 9.8±0.2 </td>
<td> 11.4±0.3 </td>
<td> 9.7±0.3 </td>
<td> 14.0±0.3 </td>
<td> 30 </td>
<td> 0.8 </td>
<td> 64.7 </td>
<td> 82.4 </td>
<td> 5333 </td>
<td> 263 </td>
<td> 75.1 </td>
<td> 2500 </td>
</tr>
<tr> <td> EC2928 </td>
<td> 463 </td>
<td> 29.0±0.5 </td>
<td> 22.0min </td>
<td></td>
<td> 9.9±0.25 </td>
<td> 11.0±0.25 </td>
<td> 10.0±0.3 </td>
<td> 14.0±0.3 </td>
<td> 29 </td>
<td> 0.75 </td>
<td> 64 </td>
<td> 79.9 </td>
<td> 5235 </td>
<td> 252 </td>
<td> 76.98 </td>
<td> 2800 </td>
</tr>
<tr> <td> EC2928B </td>
<td> 1210 </td>
<td> 28.9+0.6-0.3 </td>
<td> 22.5min </td>
<td> 20.2 min </td>
<td> 9.9±0.25 </td>
<td> 11.4±0.25 </td>
<td> 9.9+0.3-0.2 </td>
<td> 14.0±0.25 </td>
<td> 30 </td>
<td> 0.8 </td>
<td> 64.9 </td>
<td> 80.9 </td>
<td> 5250 </td>
<td> 261 </td>
<td> 77 </td>
<td> 2500 </td>
</tr>
<tr> <td> EC2934 </td>
<td> 446 </td>
<td> 29.5±0.5 </td>
<td> 22.0min </td>
<td></td>
<td> 9.9±0.25 </td>
<td> 11.4±0.25 </td>
<td> 12.5±0.3 </td>
<td> 17.0±0.3 </td>
<td> 35 </td>
<td> 0.87 </td>
<td> 74.7 </td>
<td> 86.3 </td>
<td> 6444 </td>
<td> 315 </td>
<td> 76.98 </td>
<td> 2300 </td>
</tr>
<tr> <td> ECL2940 </td>
<td> 431 </td>
<td> 29.8±0.5 </td>
<td> 22.5min </td>
<td></td>
<td> 9.9±0.25 </td>
<td> 9.5±0.25 </td>
<td> 15.4±0.3 </td>
<td> 20.2±0.3 </td>
<td> 35.5 </td>
<td> 1.19 </td>
<td> 88.1 </td>
<td> 74.2 </td>
<td> 6538 </td>
<td> 415.8 </td>
<td> 70.88 </td>
<td> 2100 </td>
</tr>
<tr> <td> EC2947 </td>
<td> 467 </td>
<td> 29.8±0.7 </td>
<td> 22.5min </td>
<td> 21 min </td>
<td> 9.5±0.15 </td>
<td> 9.5±0.2 </td>
<td> 19.5±0.2 </td>
<td> 23.5±0.2 </td>
<td> 37.1 </td>
<td> 1.5 </td>
<td> 104.3 </td>
<td> 70.9 </td>
<td> 7399.1 </td>
<td> 534.3 </td>
<td> 69.02 </td>
<td> 1500 </td>
</tr>
<tr> <td> EC3213 </td>
<td> 1208 </td>
<td> 32.0±0.5 </td>
<td> 25.5±0.5 </td>
<td> 23 min </td>
<td> 9.9±0.25 </td>
<td> 11.4±0.25 </td>
<td> 4.05±0.15 </td>
<td> 6.2±0.15 </td>
<td> 13.5 </td>
<td> 0.5 </td>
<td> 35.3 </td>
<td> 66.9 </td>
<td> 2326 </td>
<td> 126.4 </td>
<td> 49.02 </td>
<td></td>
</tr>
<tr> <td> EC3224 </td>
<td> 1207 </td>
<td> 32.0±0.5 </td>
<td> 25.5±0.5 </td>
<td> 23 min </td>
<td> 9.9±0.25 </td>
<td> 11.4±0.25 </td>
<td> 7.6±0.2 </td>
<td> 12.0±0.2 </td>
<td> 31.1 </td>
<td> 0.5 </td>
<td> 57.2 </td>
<td> 106.8 </td>
<td> 6114 </td>
<td> 237.1 </td>
<td> 76.98 </td>
<td></td>
</tr>
<tr> <td> EC3228 </td>
<td> 457 </td>
<td> 32.0±0.6 </td>
<td> 24.6min </td>
<td></td>
<td> 9.9±0.25 </td>
<td> 11.4±0.25 </td>
<td> 9.65±0.2 </td>
<td> 14.0±0.2 </td>
<td> 33 </td>
<td> 0.77 </td>
<td> 68.1 </td>
<td> 88.5 </td>
<td> 6020 </td>
<td> 295.3 </td>
<td> 76.98 </td>
<td> 2500 </td>
</tr>
<tr> <td> EC3325 </td>
<td> 950 </td>
<td> 33.0±0.5 </td>
<td> 24.5min </td>
<td> 20.5 min </td>
<td> 14.8±0.2 </td>
<td> 17.0±0.25 </td>
<td> 6.8±0.2 </td>
<td> 12.3±0.2 </td>
<td> 50.9 </td>
<td> 0.3 </td>
<td> 54.5 </td>
<td> 174 </td>
<td> 8483 </td>
<td> 138.7 </td>
<td> 171.52 </td>
<td> 4800 </td>
</tr>
<tr> <td> EC3435 </td>
<td> 798 </td>
<td> 34.2±0.6 </td>
<td> 25.6min </td>
<td></td>
<td> 10.8±0.3 </td>
<td> 10.8±0.3 </td>
<td> 12.1±0.3 </td>
<td> 17.3±0.2 </td>
<td> 41.4 </td>
<td> 0.8 </td>
<td> 78.5 </td>
<td> 97.9 </td>
<td> 7640 </td>
<td> 370.3 </td>
<td> 91.61 </td>
<td> 2700 </td>
</tr>
<tr> <td> EC3543 </td>
<td> 450 </td>
<td> 35.0±0.6 </td>
<td> 26.0min </td>
<td></td>
<td> 11.3±0.3 </td>
<td> 11.3±0.3 </td>
<td> 15.5±0.3 </td>
<td> 21.5±0.3 </td>
<td> 51.6 </td>
<td> 0.86 </td>
<td> 93.1 </td>
<td> 103.3 </td>
<td> 9590 </td>
<td> 471.2 </td>
<td> 100.29 </td>
<td> 2500 </td>
</tr>
<tr> <td> ECL3543 </td>
<td> 465 </td>
<td> 35.3±0.6 </td>
<td> 26.4min </td>
<td></td>
<td> 11.3±0.3 </td>
<td> 11.3±0.3 </td>
<td> 15.5±0.3 </td>
<td> 21.5±0.3 </td>
<td> 52 </td>
<td> 0.87 </td>
<td> 93.5 </td>
<td> 107.3 </td>
<td> 10030 </td>
<td> 486.7 </td>
<td> 100.29 </td>
<td> 2500 </td>
</tr>
<tr> <td> EC3643 </td>
<td> 419 </td>
<td> 36.0±0.6 </td>
<td> 26.5min </td>
<td></td>
<td> 11.3±0.3 </td>
<td> 11.3±0.3 </td>
<td> 15.6±0.3 </td>
<td> 21.6±0.3 </td>
<td> 56 </td>
<td> 0.85 </td>
<td> 94.2 </td>
<td> 110.7 </td>
<td> 10420 </td>
<td> 489.8 </td>
<td> 100.29 </td>
<td> 2300 </td>
</tr>
<tr> <td> ECL3643 </td>
<td> 422 </td>
<td> 36.3±0.6 </td>
<td> 27.8min </td>
<td></td>
<td> 11.3±0.3 </td>
<td> 11.3±0.3 </td>
<td> 15.6±0.3 </td>
<td> 21.6±0.3 </td>
<td> 54.2 </td>
<td> 0.87 </td>
<td> 94.9 </td>
<td> 106.3 </td>
<td> 10083 </td>
<td> 530.4 </td>
<td> 99.11 </td>
<td> 2300 </td>
</tr>
<tr> <td> EC38 </td>
<td> 1270 </td>
<td> 38.0±0.5 </td>
<td> 28min </td>
<td> 24.0±0.4 </td>
<td> 17.3±0.2 </td>
<td> 20.0±0.25 </td>
<td> 7.3±0.2 </td>
<td> 13.3±0.2 </td>
<td> 74.2 </td>
<td> 0.25 </td>
<td> 59.2 </td>
<td> 238.5 </td>
<td> 14119.2 </td>
<td></td>
<td></td>
<td></td>
</tr>
<tr> <td> EC3942 </td>
<td> 439 </td>
<td> 39.0±0.6 </td>
<td> 29.5min </td>
<td></td>
<td> 12.5±0.3 </td>
<td> 12.5±0.3 </td>
<td> 15.8±0.3 </td>
<td> 21.0±0.3 </td>
<td> 65 </td>
<td> 0.78 </td>
<td> 96.8 </td>
<td> 124.8 </td>
<td> 12089 </td>
<td> 553 </td>
<td> 122.72 </td>
<td> 2500 </td>
</tr>
<tr> <td> EC39A </td>
<td> 470 </td>
<td> 39.0±0.4 </td>
<td> 28.63min </td>
<td></td>
<td> 12.8±.2 </td>
<td> 12.8±0.2 </td>
<td> 17.0±0.25 </td>
<td> 22.7±0.25 </td>
<td> 68.5 </td>
<td> 0.7 </td>
<td> 102.4 </td>
<td> 138.1 </td>
<td> 14090 </td>
<td> 550.8 </td>
<td> 128.68 </td>
<td> 2800 </td>
</tr>
<tr> <td> EC4045 </td>
<td> 499 </td>
<td> 40.0±0.7 </td>
<td> 29.0min </td>
<td></td>
<td> 13.3±0.3 </td>
<td> 13.3±0.3 </td>
<td> 15.5±0.3 </td>
<td> 22.5±0.3 </td>
<td> 78.5 </td>
<td> 78.5 </td>
<td> 98 </td>
<td> 149 </td>
<td> 14600 </td>
<td> 502.2 </td>
<td> 138.93 </td>
<td> 3000 </td>
</tr>
<tr> <td> EC4045A </td>
<td> 1247 </td>
<td> 40±0.6 </td>
<td> 31.0±0.5 </td>
<td> 28.9±0.5 </td>
<td> 12.5±0.3 </td>
<td> 12.5±0.3 </td>
<td> 17.3±0.2 </td>
<td> 22.8±0.3 </td>
<td> 65.5 </td>
<td> 0.83 </td>
<td> 104.7 </td>
<td> 126.2 </td>
<td> 13219 </td>
<td></td>
<td></td>
<td> 3000 </td>
</tr>
<tr> <td> EC4145 </td>
<td> 421 </td>
<td> 41.0±0.7 </td>
<td> 29.2min </td>
<td></td>
<td> 13.3±0.3 </td>
<td> 13.3±0.3 </td>
<td> 15.5±0.3 </td>
<td> 22.5±0.3 </td>
<td> 81.5 </td>
<td> 81.5 </td>
<td> 97.4 </td>
<td> 156.9 </td>
<td> 15290 </td>
<td> 508.4 </td>
<td> 138.93 </td>
<td> 3200 </td>
</tr>
<tr> <td> EC4235 </td>
<td> 447 </td>
<td> 42.0±07 </td>
<td> 31.6min </td>
<td></td>
<td> 12.8±0.3 </td>
<td> 12.8±.3 </td>
<td> 12.5±0.3 </td>
<td> 17.7±0.3 </td>
<td> 61.6 </td>
<td> 0.65 </td>
<td> 86.38 </td>
<td> 133.87 </td>
<td> 11564 </td>
<td> 470 </td>
<td> 128.68 </td>
<td> 3000 </td>
</tr>
<tr> <td> EC4242A </td>
<td> 454 </td>
<td> 42.0±0.7 </td>
<td> 31.7min </td>
<td></td>
<td> 17.3±0.3 </td>
<td> 19.6±0.3 </td>
<td> 15.3±0.3 </td>
<td> 21.3±0.3 </td>
<td> 117.6 </td>
<td> 0.4 </td>
<td> 94.1 </td>
<td> 234.5 </td>
<td> 22080 </td>
<td> 455.9 </td>
<td> 233.57 </td>
<td> 4600 </td>
</tr>
<tr> <td> EC4245 </td>
<td> 498 </td>
<td> 42.0±0.7 </td>
<td> 30.5min </td>
<td></td>
<td> 15.2±0.3 </td>
<td> 15.2±0.3 </td>
<td> 15.4±0.3 </td>
<td> 22.4±0.3 </td>
<td> 98.9 </td>
<td> 0.51 </td>
<td> 97.6 </td>
<td> 190.3 </td>
<td> 18569 </td>
<td> 486.6 </td>
<td> 181.46 </td>
<td> 3600 </td>
</tr>
<tr> <td> EC4343A </td>
<td> 494 </td>
<td> 43.0±0.7 </td>
<td> 33.0min </td>
<td></td>
<td> 17.3±0.3 </td>
<td> 19.6±0.3 </td>
<td> 15.4±0.3 </td>
<td> 21.4±0.3 </td>
<td> 118.3 </td>
<td> 0.41 </td>
<td> 95.9 </td>
<td> 231.6 </td>
<td> 22198 </td>
<td> 499 </td>
<td> 225.87 </td>
<td> 4800 </td>
</tr>
<tr> <td> EC4344B </td>
<td> 441 </td>
<td> 43.0±0.7 </td>
<td> 31.5min </td>
<td></td>
<td> 15.0±0.3 </td>
<td> 15.0±0.3 </td>
<td> 15.3±0.3 </td>
<td> 22.0±0.3 </td>
<td> 96.5 </td>
<td> 0.53 </td>
<td> 98 </td>
<td> 184.8 </td>
<td> 18112 </td>
<td> 520.2 </td>
<td> 176.71 </td>
<td> 3600 </td>
</tr>
<tr> <td> EC4345 </td>
<td> 443 </td>
<td> 43.0±0.7 </td>
<td> 31.5min </td>
<td></td>
<td> 15.2±0.3 </td>
<td> 15.2±0.3 </td>
<td> 15.6±0.3 </td>
<td> 22.4±0.3 </td>
<td> 99.9 </td>
<td> 0.52 </td>
<td> 99.2 </td>
<td> 189 </td>
<td> 18750 </td>
<td> 524.2 </td>
<td> 181.46 </td>
<td> 3600 </td>
</tr>
<tr> <td> EC4345C </td>
<td> 442 </td>
<td> 43.0±0.7 </td>
<td> 31.0min </td>
<td></td>
<td> 15.5±0.3 </td>
<td> 15.5±0.3 </td>
<td> 15.5±0.3 </td>
<td> 22.5±0.3 </td>
<td> 104.3 </td>
<td> 0.5 </td>
<td> 98.5 </td>
<td> 198.8 </td>
<td> 19581 </td>
<td> 496 </td>
<td> 188.69 </td>
<td> 3600 </td>
</tr>
<tr> <td> EC4348 </td>
<td> 460 </td>
<td> 43.0±0.7 </td>
<td> 31.0min </td>
<td></td>
<td> 15.5±0.3 </td>
<td> 15.5±0.3 </td>
<td> 16.0±0.3 </td>
<td> 23.8±0.3 </td>
<td> 108 </td>
<td> 0.51 </td>
<td> 104.3 </td>
<td> 206.1 </td>
<td> 21488 </td>
<td> 496 </td>
<td> 188.69 </td>
<td> 3600 </td>
</tr>
<tr> <td> EC4443A </td>
<td> 464 </td>
<td> 44.0±0.7 </td>
<td> 34.0min </td>
<td></td>
<td> 17.3±0.3 </td>
<td> 19.6±0.3 </td>
<td> 15.6±0.3 </td>
<td> 21.4±0.3 </td>
<td> 110 </td>
<td> 0.43 </td>
<td> 101.7 </td>
<td> 235.7 </td>
<td> 23982 </td>
<td> 521 </td>
<td> 227.36 </td>
<td> 4800 </td>
</tr>
<tr> <td> EC4445 </td>
<td> 451 </td>
<td> 44.0±0.7 </td>
<td> 32.5min </td>
<td></td>
<td> 14.8±0.3 </td>
<td> 14.8±0.3 </td>
<td> 16.4±0.3 </td>
<td> 22.3±0.3 </td>
<td> 94 </td>
<td> 0.58 </td>
<td> 102.5 </td>
<td> 173 </td>
<td> 17800 </td>
<td> 597 </td>
<td> 172.03 </td>
<td> 3800 </td>
</tr>
<tr> <td> EC4949A </td>
<td> 423 </td>
<td> 49.0±0.8 </td>
<td> 36.5min </td>
<td></td>
<td> 16.3±0.3 </td>
<td> 16.3±.3 </td>
<td> 18.2±0.3 </td>
<td> 24.5±0.3 </td>
<td> 126.3 </td>
<td> 0.54 </td>
<td> 113.8 </td>
<td> 210.2 </td>
<td> 23942 </td>
<td> 753.5 </td>
<td> 205.38 </td>
<td> 4200 </td>
</tr>
<tr> <td> EC4954 </td>
<td> 495 </td>
<td> 49.0±0.8 </td>
<td> 36.5min </td>
<td></td>
<td> 17.2±0.3 </td>
<td> 17.2±0.3 </td>
<td> 18.7±0.3 </td>
<td> 27.0±0.3 </td>
<td> 150.5 </td>
<td> 0.49 </td>
<td> 117.6 </td>
<td> 242.4 </td>
<td> 28502 </td>
<td> 740.5 </td>
<td> 230.13 </td>
<td> 4500 </td>
</tr>
<tr> <td> ECL4955 </td>
<td> 433 </td>
<td> 49.0±1.0 </td>
<td> 37.6min </td>
<td></td>
<td> 17.0±0.3 </td>
<td> 17.0±0.3 </td>
<td> 18.4±0.3 </td>
<td> 27.4±0.3 </td>
<td> 144 </td>
<td> 0.5 </td>
<td> 117.1 </td>
<td> 233 </td>
<td> 27274 </td>
<td> 776.5 </td>
<td> 207.48 </td>
<td> 4200 </td>
</tr>
<tr> <td> EC5346 </td>
<td> 420 </td>
<td> 53.4±0.8 </td>
<td> 38.7min </td>
<td></td>
<td> 20.0±0.3 </td>
<td> 21.5±0.3 </td>
<td> 16.3±0.3 </td>
<td> 23.2±0.3 </td>
<td> 180 </td>
<td> 0.33 </td>
<td> 106.6 </td>
<td> 319.8 </td>
<td> 34085 </td>
<td> 625.9 </td>
<td> 296.7 </td>
<td> 6200 </td>
</tr>
<tr> <td> EC5448A </td>
<td> 493 </td>
<td> 54.0±0.8 </td>
<td> 40.0min </td>
<td></td>
<td> 20.0±0.3 </td>
<td> 21.0±0.3 </td>
<td> 16.0±0.3 </td>
<td> 23.8±0.3 </td>
<td> 183.3 </td>
<td> 0.34 </td>
<td> 108.5 </td>
<td> 321 </td>
<td> 34817 </td>
<td> 656 </td>
<td> 314.16 </td>
<td> 6300 </td>
</tr>
<tr> <td> EC5450 </td>
<td> 497 </td>
<td> 54.2±0.8 </td>
<td> 41.0min </td>
<td></td>
<td> 18.9±0.3 </td>
<td> 18.9±0.3 </td>
<td> 17.5±0.3 </td>
<td> 25.1±0.3 </td>
<td> 170.1 </td>
<td> 0.42 </td>
<td> 116 </td>
<td> 277.7 </td>
<td> 32223 </td>
<td> 791 </td>
<td> 268.06 </td>
<td> 4800 </td>
</tr>
<tr> <td> EC5548 </td>
<td> 458 </td>
<td> 55.2±0.8 </td>
<td> 38.4min </td>
<td></td>
<td> 20.0±0.3 </td>
<td> 21.5±0.3 </td>
<td> 16.2+0.2-0.3 </td>
<td> 24.2±0.3 </td>
<td> 194 </td>
<td> 0.33 </td>
<td> 112.3 </td>
<td> 344.5 </td>
<td> 38679 </td>
<td> 596.2 </td>
<td> 314.16 </td>
<td> 6300 </td>
</tr>
<tr> <td> EC5962 </td>
<td> 418 </td>
<td> 59.8±1.4 </td>
<td> 43.6min </td>
<td></td>
<td> 21.6±0.5 </td>
<td> 21.6±0.5 </td>
<td> 22.45±0.4 </td>
<td> 31.0±0.4 </td>
<td> 271.9 </td>
<td> 0.37 </td>
<td> 139.2 </td>
<td> 368 </td>
<td> 51500 </td>
<td> 1010.3 </td>
<td> 366.44 </td>
<td> 6000 </td>
</tr>
<tr> <td> EC7069 </td>
<td> 436 </td>
<td> 70.0±0.15 </td>
<td> 45.0±1.2 </td>
<td></td>
<td> 16.4±0.4 </td>
<td> 16.4±0.4 </td>
<td> 22.75±0.4 </td>
<td> 34.5±0.4 </td>
<td> 207.5 </td>
<td> 0.49 </td>
<td> 139.1 </td>
<td> 282.5 </td>
<td> 39297 </td>
<td> 1278.6 </td>
<td> 211.24 </td>
<td> 4200 </td>
</tr>
</tbody>
</table>
</div>
</start>
Wuxi Spinel Magnetics Co., Ltd.
Add.: Five-star industrial park, Donggang town, Xishan District, Wuxi, Jiangsu province, China.
Tel.:
+86-510-88353562
+86-510-88765812
Fax: +510-88769572
Contact person:
Mr. Ripeng Ho / Ms. YAO
E-mail: Sales@spinel.cn
